Technology transfer possible

Features

• - Photonic heating / sintering / UV curing / annealing

• - High peak power using pulsed xenon flash lamp

• - Rapid Thermal Processing
• - Intense Pulsed Light ( IPL )
• - Includes flash lamp power supply
• - Easy Operating Software to Pulse Shaping
• - Good Uniformity with a High Efficiency Optical Reflector
• - Large area (158mm x 75mm) irradiation

• - Max radiant energy intensity  170J/cm²
• - Pulse enegry, max. 19000J

• - Thermal Measurement (Option)
•


Applications

Material Synthesis
Flash Lamp Annealing
Photothermal Annealing
Flash Annealing
Thermal Annealing
Flash Thermal
Photothermal Shock
Flash SinteringJoule Heating
Sintering, Curing, Sterilization

• 인쇄전자 나노 잉크 경화

• 광소결, 광경화, 가열, 살균

• 급속경화, 웨이퍼 급속 열처리 장비 (RTP)

• 제논 플래시 램프 어닐링 시스템 (FLA)
